Motherboard Connector Flex Cable
Samsung Galaxy S20 FE 5G Motherboard Connector Flex Cable Replacement
- Fits
- Samsung Galaxy S20 FE 5G
- Fixes
- Board link faults
- Quality
- Brand new, OEM quality
- Fitting
- Professional install
Overview
What this part is
In the S20 FE, the charging port, loudspeaker and bottom microphone sit on a sub board at the bottom of the phone. A long flex cable carries power and signals between that sub board and the main board. If it is torn during a repair, or damaged by a drop or liquid, several lower-board functions can fail at once.
This part replaces that connector flex. It is a good fix when a charging port swap did not help, or after the old flex was damaged while the phone was open.
Compatibility
Specifications and compatibility
- Part
- Motherboard Connector Flex Cable
- Compatible with
- Samsung Galaxy S20 FE 5G
- Model numbers
- SM-G781B
- Does not fit
- Galaxy S20, S20+, S21 FE or any other model
- Fixes
- Charging, bottom microphone or loudspeaker faults caused by a torn or damaged main flex
- Does not fix
- A faulty charging port board, battery, screen or main board chip faults
- Quality
- Brand new, OEM-quality motherboard connector flex cable for the Galaxy S20 FE. Tested before dispatch.
- Brand
- Unbranded, compatible with Samsung Galaxy S20 FE 5G
- In the box
- 1 × Galaxy S20 FE motherboard connector flex cable.
- Colour
- As shown in the photos
- Installation
- Professional installation recommended
- Supplied by
- Supreme Phone Parts Ltd, Manchester, UK
Before you order
Is this the right part?
Signs it needs replacing
- The phone stopped charging after a repair or drop
- The bottom microphone or loudspeaker cut out together
- A new charging port board did not fix charging
- The flex cable is visibly torn or creased
How to check your model
Open Settings › About phone. The model name should read Galaxy S20 FE 5G. The model number starts SM-G781B.
If your model number is SM-G780F (4G), contact us before ordering so we can confirm fit.
Professional installation
How a technician fits this part
- Power the phone off and remove the SIM tray.
- Heat and remove the back cover, then remove the covers over both boards.
- Disconnect the battery before any other connector.
- Unclip the old flex from the main board and sub board and peel it free.
- Lay the new flex in the same path, connect both ends and test charging, sound and microphone.
- Refit the covers and seal the back cover with new adhesive.
Check that the part matches the device before fitting it or removing any adhesive backing. Once a part has been fitted, it cannot be returned for a change of mind. Faulty parts are always covered.
FAQ
Frequently asked questions
Will this fit my Galaxy S20 FE?
Yes, if your model number is SM-G781B. For the 4G model (SM-G780F), contact us first to confirm.
Does it fit the Galaxy S21 FE?
No. The S21 FE uses a different flex and layout.
How do I know it is the flex and not the charging port?
If charging, the loudspeaker and the bottom microphone all fail together, the flex is a likely cause. If only charging fails, try the charging port board first.
Is it made by Samsung?
No. It is a brand new, OEM-quality motherboard connector flex cable made to fit the Galaxy S20 FE, and every part is tested before dispatch.
Should I fit it myself?
We recommend professional installation. The flex is long and thin and runs under the battery area, so it tears easily if handled roughly.
How quickly will it arrive?
Orders placed before 4pm on a working day are dispatched the same day from Manchester by Royal Mail Tracked. Delivery is free on UK orders from £5.
Prepared by the Supreme Phone Parts team, Manchester. Last updated September 2026.
