Loudspeaker
Google Pixel 9 Pro XL Loudspeaker Replacement
- Fits
- Google Pixel 9 Pro XL
- Fixes
- Quiet or crackling speaker
- Quality
- Brand new, OEM quality
- Fitting
- Professional install
Overview
What this part is
The loudspeaker at the bottom of the Google Pixel 9 Pro XL plays ringtones, alarms, music and speakerphone calls. Water, dust and drops can damage the speaker so it sounds quiet, rattles or stops working.
This is the bottom loudspeaker unit only. The top speaker used for calls is a separate part. Before ordering, clean the speaker grille and check the volume and Bluetooth settings. Fitting it means opening the phone from the screen side.
Compatibility
Specifications and compatibility
- Part
- Loudspeaker
- Compatible with
- Google Pixel 9 Pro XL
- Model numbers
- GGX8B
- Does not fit
- Pixel 9, Pixel 9 Pro, Pixel 8 Pro or any other model
- Fixes
- Quiet, distorted, crackling or silent ringtones, media and speakerphone
- Does not fix
- Top speaker, microphone, charging or main board faults
- Quality
- Brand new, OEM-quality loudspeaker. Tested before dispatch.
- Brand
- Unbranded, compatible with Google Pixel 9 Pro XL
- In the box
- 1 × loudspeaker for Google Pixel 9 Pro XL.
- Colour
- As shown in the photos
- Installation
- Professional installation recommended
- Supplied by
- Supreme Phone Parts Ltd, Manchester, UK
Before you order
Is this the right part?
Signs it needs replacing
- Ringtones and alarms are quiet or silent
- Music and videos crackle or rattle at high volume
- Speakerphone calls sound distorted
- Sound works in headphones but not from the phone
How to check your model
Open Settings › About phone. The device name should read Pixel 9 Pro XL, not Pixel 9 Pro. The model code (GGX8B) is shown in Settings › About phone › Regulatory labels and on the box.
The Pixel 9 Pro XL has a 6.8-inch screen and three rear cameras. The Pixel 9 Pro is smaller (6.3-inch).
Professional installation
How a technician fits this part
- Power the Pixel 9 Pro XL off and remove the SIM tray.
- Warm the screen edges and open the phone carefully from the display side.
- Disconnect the battery before touching any other part.
- Remove the parts covering the old loudspeaker and lift it out.
- Fit the new loudspeaker, making sure any gaskets and contacts sit correctly.
- Reassemble with new adhesive and test sound, calls and media at full volume.
Check that the part matches the device before fitting it or removing any adhesive backing. Once a part has been fitted, it cannot be returned for a change of mind. Faulty parts are always covered.
FAQ
Frequently asked questions
Will this fit my Pixel 9 Pro XL?
Yes, if Settings › About phone shows Pixel 9 Pro XL. It fits models GGX8B.
Does it fit the Pixel 9 Pro?
No. The Pixel 9 Pro is smaller (6.3-inch), and it uses a different part. This loudspeaker is for the Pixel 9 Pro XL only.
Will this fix quiet phone calls at my ear?
No. Call audio at your ear comes from the top speaker. This loudspeaker covers ringtones, media and speakerphone.
Is it made by Google?
No. It is a brand new, OEM-quality loudspeaker made to fit the Google Pixel 9 Pro XL, and every part is tested before dispatch.
Should I fit it myself?
We recommend professional installation. The Pixel 9 Pro XL opens from the screen side with heat and adhesive, and the battery must be disconnected safely.
How quickly will it arrive?
Orders placed before 4pm on a working day are dispatched the same day from Manchester by Royal Mail Tracked. Delivery is free on UK orders over £5. You can also collect from our shop at 33 Moulton Street, Manchester M8 8FQ.
Prepared by the Supreme Phone Parts team, Manchester. Last updated September 2026.
